    Hydraulic Aluminum / Steel Coil Slitting Line Cold Rolled Steel Sheet Slitting Equipment

    Ask Lasest Price
    Brand Name : Guangcai
    Certification : CE
    Model Number : GWC1250-3mm aluminum coil
    Price : Negotiation
    Delivery Time : 120 days
    Payment Terms : T/T
    Supply Ability : 10 sets/year
    • Product Details
    • Company Profile

    Hydraulic Aluminum / Steel Coil Slitting Line Cold Rolled Steel Sheet Slitting Equipment


    Hydraulic Aluminum / Steel Coil Slitting Line Cold Rolled Steel Sheet Slitting Equipment


    Quick Detail:


    Composition


    This aluminum coil slitting machine consists of several parts, as listed below.


    1. Hydraulic loading car
    2. Dual-head decoiler
    3. Coil head drawing machine
    4. Clamp-feeding and leveling machine
    5. Cross cut shear for panel head
    6. Loop bridge
    7. Side stop device
    8. Main slitting machine

    9. Scrap baller
    10. Transmission parts
    11. Separator
    12. Damp tensioning device
    13. Main hydraulic recoiler
    14. Hydraulic unloading car
    15. Hydraulic system
    16. Electrical control system


    Working process:


    Hydraulic decoiling → material storing → vertical guiding → shearing → correction → material storing → tensioning → rewinding


    Description:


    Introduction


    The aluminum coil slitting line, also known as a slitting machine or simply a slitter, is a shearing device that cuts a large roll of steel into narrower rolls. The following paragraphs give a brief introduction to this equipment in several aspects.


    1. Function


    Our product could cut metal coils longitudinally, and then rewind the slit pieces into coils.


    2. Advantage


    This machine is characterized by convenient operation, excellent cutting quality, stepless speed control, high utilization percentage of the steel, etc.


    3. Structure


    The aluminum coil slitting line is mainly composed of decoiler, feeder, slitter and recoiler.


    4. Applicable Material


    Our product is able to process various kinds of materials, including tinplate, copper plate, aluminum strip, silicon steel sheet, stainless steel sheet, galvanized plate and more.


    5. Applicable Field


    Owing to the properties above, this product is commonly used for the production of transformers, motors, automobiles, packages, building materials, household appliances an others.


    Applications:


    1. steel coil
    2. aluminum coil

    Specifications


    ModelGWC1250-3mm aluminum coilNote
    Applicable materialCold rolled sheet, color plate, pickled plate and galvanized plateThis machine is customizable upon each customer's requirements and the characteristics of processed material.
    Feeding width1250mm
    Processing thickness1.0mm - 3.0mm
    Blade material6CrW2Si, HRC58°-60°
    Main motor power / hydraulic station powerZ4-180-41-55kW DC motorThese parameters can be set according to the required production capacity.
    Forming passes18
    Forming speed0-80 meters/minute
    Machine dimensions26×7×1.5m
    Machine weight30T
